$2,625.00 SGD $3,396.00 SGD
| /
| Brand | CUSCO |
| Series Name | SPORT TN_S SINGLE-CYLINDER COILOVER SUSPENSION KIT |
| Product Number | 1H1 64W CN |
| Compatible Car | TOYOTA GR COROLLA GZEA14H |
| Compatible Engine | |
| Product Description | Grade: RZ RZ Morizo Edition Drive system: 4WD Displacement: 1600T Upper Mount (F/R): PAJ/ARG Damping force adjustment (F/R): 24 2way/24 2way OH (F/R): ○/○ Model vehicle: Morizo Edition Recommended vehicle height adjustment range (mm) (F/R): -40~-10/-50~-5 Reference vehicle height: -25 / -30 Maximum adjustment range (mm) (F/R): -45~0/-65~-5 Standard spring rate (kgf/mm) (F/R): 8K/12K Changeable spring (F/R): 7/9~12 / 7~11/14/16 ID/FH (F/R): 65/200 / 65/varies depending on rate Garage adjustment mechanism (F/R): Full length adjustment / Screw spacer OPTION - |
| Remarks | The front camber angle can be adjusted by the knuckle bracket eccentric collar. Combined with the upper mount adjustment, it can be adjusted from -1.0° to -4.5° (reference value). |
| Notes | Images are for illustration purpose only. Actual product may vary. |
