$2,474.00 SGD $3,201.00 SGD
| /
| Brand | CUSCO |
| Series Name | SPORT TN_R SINGLE-CYLINDER COILOVER SUSPENSION KIT |
| Product Number | 965 64V CP |
| Compatible Car | TOYOTA 86 ZN6 KOUKI |
| Compatible Engine | |
| Product Description | Grade: GT Limited GT G RC Drive system: FR Displacement: 2000 Upper Mount (F/R): PAJ/PRG Damping force adjustment (F/R): 24 2way/24 2way OH (F/R): ○/○ Model vehicle: Late model Recommended vehicle height adjustment range (mm) (F/R): -40~0/-35~0 Reference vehicle height: -15 / -25 Maximum adjustment range (mm) (F/R): -55~0/-70~0 Standard spring rate (kgf/mm) (F/R): 12K/10K Changeable spring (F/R): 7~11/13~16 / 7/8/9/11~16/18 ID/FH (F/R): 65/150 / 65/150 Garage adjustment mechanism (F/R): Full length adjustment / Full length adjustment OPTION CCP |
| Remarks | When adjusting the vehicle height of early models, attention must be paid to the height of the front bumper turn signal lens (the bottom end must be 350mm or more from the ground). The reference limit is about 15mm lower than the stock. The camber angle can be adjusted on the front using the knuckle eccentric bolt. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
