RECARO BASE FRAME SEAT RAIL LEFT SEAT FOR AUDI A5 S5 RS5 8T### 2012.513.1

RECARO

BASE FRAME SEAT RAIL LEFT SEAT

2012.513.1

AUDI A5 S5 RS5 8T###

Model year: 2008-02-2017-04
Special notes: The side airbag function built into the factory seat will be lost. The airbag warning light needs to be turned off. The seat position sensor needs to be relocated. The seating position will be approximately 65mm lower than the highest position of the factory seat height adjustment function, and approximately 15mm higher than the lowest position (when installing the 19mm (standard 6mm and 13mm) spacer for ST-JJ). Since the seating position feels low, please use the included 13mm spacer between the Recaro seat and the seat rail if it is installed. Seat offset door side approximately 15mm (Recaro moves closer to the door). The slide amount is approximately 15mm less front and rear compared to the factory.
Notes / Interference information: Seat slide position At the very front, there is a slight interference of about 1mm between the center console and the front end of the seat cushion for the AM19 SPORT, Orthoped, and IS-05 series of SR-6, 7, and 11. SP-# and Racer require the SP-G offset adapter set (product number 1600094J). For RS/TS-#, the RS/TS-G offset adapter set (product number 1700001J) allows the handlebar offset to be adjusted in 5mm increments from 5mm to a maximum of 15mm. (Please consult your dealer regarding interference with the console (shift, etc.) when installing.) For RMS, adjust to the optimal position (front-to-back height, left-to-right offset 0/5/10mm) using the separately sold RMS side adapter. Also, if there is interference with the interior, it can be alleviated by adjustment. For RCS, adjust to the optimal position (front-to-back height, left-to-right offset 0/5/10mm) using the separately sold RCS side adapter.
Position: New structure frame. One-position type.
Armrest: Not mountable
Compatible seats: LX / LX-# / LX-VS / LX-VF / LX-VL / Ergomed / Ergomed C / Ergomed D / Ergomed E / Ergomed LD / Ergomed MV (IS-84 base)
Classic LX Pepita / Classic LX Spektrum
LX-F (IS-05 base)
LS / LS-# / LT-#
Pro Racer RMS RMS should be adjusted to the optimal position (front-rear height, left-right offset 0/5/10mm) using the separately sold RMS side adapter . Also, if there is interference with the interior, it can be mitigated by adjusting it. New Orthoped (with Recaro vent)
RCS Please adjust the RCS to the optimal position (front/rear height, left/right offset 0/5/10mm) using the separately sold RCS side adapter before installation. *Please choose from the following two types. ・RCS side adapter ・RCS stainless steel side adapter set SP-A / SP-G / SP-G2 / SP-G3 / SP-GT / SP-GT2 SP-#, Racer requires the separately sold SP-G offset adapter set . SP-AN / SP-GN / SP-GN 2 SP-AN / SP-GN / SP-GN 2 requires the separately sold SP-GN side adapter set . PRO RACER(RACER) SP-G/A SP-# and Racer require the separately sold SP-G offset adapter set (product number 1600094J). AM19 TREND-J/JJ/JC
AM19 STYLE-J/JJ/JC
AM19 SPORT-J/JJ/JC
AM19 TREND-JS
AM19 STYLE-JS
AM19 SPORT-JS
AM19 TREND-D/DC
AM19 STYLE-D/DC
AM19 SPORT-D/DC/MAGNIFICA CL222HV
TS-G / RS-G / TS-W / RS-W For RS/TS-# series, please choose from two types of side adapter set or offset adapter set for RS/TS-G, both sold separately. [Priority on seating position] Side adapter set [Priority on offset] Offset adapter set for RS/TS-G Handle offset can be adjusted to 5/10/15mm left and right. (Seating position is raised by +5mm.) SP-X
SR-6 /SR-11/SR-7
SR-S
SR-C/ SR-7F
Sportster
CrossSportster

(Note) This product cannot be installed on any seats other than those listed in the matching information below. For B8 driver's seat. Side airbag canceller included. Compatibility with vehicles equipped with optional items has not been confirmed.

Images are for illustration purpose only. Actual product may vary.
