RECARO BASE FRAME SEAT RAIL LEFT SEAT FOR SUZUKI JIMNY JB23W 2088.015.1

RECARO

BASE FRAME SEAT RAIL LEFT SEAT

2088.015.1

SUZUKI JIMNY JB23W

Model year: 1998-01-2018-06
Special notes: The seating position is almost the same as the genuine seat (ST-JJ center hole used).
Notes / Interference information: For LX (including Ergomed), LS, and LT, the backrest side and door armrest interfere by about 5 to 10 mm. For New Ortho (sold until October 2010), the backrest side and door armrest interfere by about 5 to 10 mm when installed with the backrest width adjustment set to the narrowest position. For New Ortho sold after November 2010, the width adjustment function is not a dial type but an electric type, but the backrest side and door armrest interfere by about 5 to 10 mm. For Style-J, JJ, JC, D, and DC, the backrest side and door armrest interfere by about 10 to 15 mm when installed with the backrest width adjustment set to the narrowest position (the air lumbar support pump interferes with the door, making it difficult to use). Style-JS is installed with the backrest width adjustment set to the narrowest setting. Sport-JS has a few mm of interference between the side of the backrest and the door armrest, and in manual transmission vehicles, the side of the seat cushion interferes with the shift lever, making it difficult to put into gear. RMS should be adjusted to the optimal position (front-to-back height, left-to-right offset 0/5/10mm) using the separately sold RMS side adapter before installation. Any interference with the interior can also be alleviated by adjustment. RCS should be adjusted to the optimal position (front-to-back height, left-to-right offset 0/5/10mm) using the separately sold RCS side adapter before installation.
Position: New structure frame. English: Choose from 3 heights (For some car models, the legs of the slide rail may need to be cut depending on the installation position, so please test fit before installation.)
Armrest: Can be installed for the right hand of the left seat, or the left hand of the right seat
Compatible seats: LX / LX-# / LX-VS / LX-VF / LX-VL / Ergomed / Ergomed C / Ergomed D / Ergomed E / Ergomed LD / Ergomed MV (IS-84 base)
Classic LX Pepita / Classic LX Spektrum
LX-F (IS-05 base)
LS / LS-# / LT-#
Pro Racer RMS For the RMS, please adjust to the optimal position (front/back height, left/right offset 0/5/10mm) using the separately sold RMS side adapter . Also, if there is interference with the interior, it can be mitigated by adjustment. New Orthoped (with Recaro vent)
RCS Please adjust the RCS to the optimal position (front/rear height, left/right offset 0/5/10mm) using the separately sold RCS side adapter before installation. *Please choose from the following two types. ・RCS side adapter ・RCS stainless steel side adapter set SP-A / SP-G / SP-G2 / SP-G3 / SP-GT / SP-GT2 You will need to prepare the side adapter set separately. SP-AN / SP-GN / SP-GN 2 SP-AN / SP-GN / SP-GN 2 require the separately sold SP-GN side adapter set . You will need to purchase the PRO RACER(RACER) SP-G/A side adapter set (product number 1700000J) separately. AM19 STYLE-J/JJ/JC
AM19 TREND-JS
AM19 STYLE-JS
AM19 SPORT-JS
AM19 STYLE-D/DC
TS-G / RS-G / TS-W / RS-W side adapter set (product number 1700000J) separately. SP-X
SR-6 /SR-11/SR-7
SR-S
SR-C/ SR-7F
Sportster
CrossSportster

(Note) This product cannot be installed on any seats other than those listed in the matching information below. The shape of this product has been changed since July 13, 2011. Thank you for your understanding.

Images are for illustration purpose only. Actual product may vary.
