$300.60 SGD
| /
| Brand | J'S RACING |
| Series Name | FF ROLL CENTER ADJUSTER |
| Product Number | FCJ-IS2 |
| Compatible Car | HONDA INSIGHT ZE2 |
| Compatible Engine | LDA-MF6 |
| Product Description | Material: Tylot End S45C Tylot End Ball Stud SCM435 Special parts that can be changed to the ideal geometry by modifying the roll center. The previous roll center adjustment effect remains the same, but by changing the working angle fulcrum, we succeeded in further improving the effect on geometry changes. [What is a roll center adjuster] When the vehicle height is lowered, the lower arm angle becomes worse and the position of the roll center is lowered too much. When the center of gravity of the car and the roll center are separated, the amount of roll increases and the cornering force is sacrificed. Also, the suspension stroke is reduced and the limit is lowered. By installing the J'S RACING roll center adjuster, the lowered roll center can be corrected to the ideal position (the distance between the center of gravity of the vehicle and the roll center is corrected to a short position), and the ideal suspension geometry is realized. increase. [Installation effect] For example, it has a great effect on vehicles with down suspension, so it has a great effect on all low-down vehicles regardless of genre. ★ Reduction of excess roll amount due to lowdown ★ Improvement of tire contact feeling and steering information ★ Steering (front tire) is quicker to respond than before ★ Cornering force (grip power) ) Is greatly increased It is a special part born from super durability and time attack participation know-how, but it is a low down fit essential part that can be used comfortably even on the street. In the lower postion of car doesn't have good condition with the lower arms. It will give high speed cornering to your car. It cause from collection with geometory of lower arm angle. Please use. * It is not recommended to install it on vehicles with a normal vehicle height up to 20 mm. Ball joint S45C Ball stud SCM435 HB195-260 Swing angle all around 39 ° 10mm extension type |
| Remarks | Engine: LDA-MF6 [Compatible model] 2010 ZE2 G HMM 1100001 2010 ZE2 L HMM 1100001 2010 ZE2 LS HMM 1100001 Press work is required for installation. We recommend that you replace it at a professional shop. It is necessary to adjust the vehicle height and alignment after replacement. Please follow the specified torque and install correctly. Need to do the alignment after install this parts. * Please check the tightening of bolts and nuts regularly after mounting. Please do this every time, especially before driving on the circuit. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
