$361.20 SGD $414.10 SGD
| /
| Brand | NISMO |
| Series Name | Circuit Link Pro Set |
| Product Descriptions | To provide an optimal camber angle, the transverse link's effective length has been extended (+4mm) and the position of the upper link's third link installation hole has been changed. Change in alignment angle, on standard vehicle height (Design specification): Before installation: -0°55' ;Gafter installation: -1°30' The figures above may vary by ±0.45, depending on the individual characteristics of each vehicle. Qty to order per car : 1 For the front left side, set of upper link (change of mounting hole position) and transverse (effective length extension product) |
| Product Number | 54502-RS595-R |
| Compatible Vehicle | Skyline GT-R (BNR34) |
| Engine | RB26DETT |
| Remark | No. : 1 Circuit Link Set and Tension Rod Set Pro. Must be used as a set. Also, when installing, you need a nut (Nissan genuine parts 01223-002814 pieces) to close the transverse link and the tension rod. Please purchase separately.Tension rod set Pro. Needs to be removed or processed because the tire interferes with the fender protector (right front side) and the recycling valve during full steering. By attaching the tension rod set Pro., The steering becomes heavier when steering. When installing the tension rod set Pro., Rear upper link set Pro. The effective length changes, the clearance of each part such as tire and fender will change. Always replace all link types on the circuit link at the same time. If you exchange only one place, the balance of suspension will collapse. No. 11 We recommend exchanging front third link bush with NISMO. By exchanging the link alone, we can not demonstrate the performance of the suspension 100%. When repairing, always replace all on one side at the same time, please exchange the bush on the opposite side for the tension rod and upper arm. In case of accident etc, there is a possibility that burden is put on all the links even if the damaged place is one place, the balance of suspension will collapse if only one place is exchanged. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
