RS-R BEST-I UPPER AND LOWER COILOVER SUSPENSION RECOMMENDED SPRING RATES FOR SUZUKI EVERY WAGON DA17W BICKJS656M

$1,418.00 SGD $1,835.00 SGD

| /

Brand
RS-R
Series Name
BEST-I UPPER AND LOWER COILOVER SUSPENSION RECOMMENDED SPRING RATES
Product Number
BICKJS656M
Compatible Car
SUZUKI EVERY WAGON DA17W
Product Description
Model year: H27/2~R1/5 (2015/2~2019/5)
Drive (Displacement): FR 660 TB
Series: Best☆i Up/Down
Recommended vehicle height adjustment range (mm) (F/R): +35~-10/+40~-10
Recommended vehicle height (mm) (F/R): +15~+10/+15~+10
Maximum adjustment range (mm) (F/R): +45~-25/+40~-10
Recommended spring rate (kg/mm) (F/R): 5.00/2.90
JAN: 838550
Damping force adjustment (F/R): ○/○
Number of adjustment steps (F/R): 36/36
Overall length adjustment (F/R): ○/×
Front camber adjustment: ※4
Rear vehicle height adjustment: Screw type
Matching grade: PZ Turbo (high roof)
Remarks: Up & down specifications. 2WD vehicles / before MC only
Remarks
Up & down specifications. For 2WD vehicles/before MC only. CAN ONLY BE SHIPPED WITH UPS OR FEDEX
Notes
Images are for illustration purpose only. Actual product may vary.
