RS-R BEST-I UPPER AND LOWER COILOVER SUSPENSION RECOMMENDED SPRING RATES FOR SUBARU FORESTER SJG BIJF908M

$1,599.00 SGD $2,069.00 SGD

| /

Brand
RS-R
Series Name
BEST-I UPPER AND LOWER COILOVER SUSPENSION RECOMMENDED SPRING RATES
Product Number
BIJF908M
Compatible Car
SUBARU FORESTER SJG
Product Description
Model year: H24/11~H29/3 (2012/11~2017/3)
Drive (Displacement): 4WD 2000 TB
Series: Best☆i Up/Down
Recommended vehicle height adjustment range (mm) (F/R): +45~-25/+45~-20
Recommended vehicle height (mm) (F/R): +15~+10/+15~+10
Maximum adjustment range (mm) (F/R): +75~-95/+70~-70
Recommended spring rate (kg/mm) (F/R): 7.00/6.00
JAN: 838369
Damping force adjustment (F/R): ○/○
Number of adjustment steps (F/R): 36/36
Overall length adjustment (F/R): ○/○
Front camber adjustment: ○
Rear vehicle height adjustment: Full length type
Matching grade: 2.0XT EyeSight
Remarks: Up & down specification Applied model E type not confirmed
Remarks
Up & Down specification Applied model E type unconfirmed CAN ONLY BE SHIPPED WITH UPS OR FEDEX
Notes
Images are for illustration purpose only. Actual product may vary.
