RS-R BLACK-I COILOVER SUSPENSION RECOMMENDED SPRING RATE FOR LEXUS GS350 GRL10 BKT170M

$1,645.00 SGD $2,127.00 SGD

| /

Brand
RS-R
Series Name
BLACK-I COILOVER SUSPENSION RECOMMENDED SPRING RATE
Product Number
BKT170M
Compatible Car
LEXUS GS350 GRL10
Product Description
Model year:H24/1-H27/10 (2012/1-2015/10)
Drive (Displacement):FR 3500 NA
Series:Black☆i
Recommended vehicle height adjustment range (mm) (F/R):-50~-80/-65~-90
Recommended vehicle height (mm) (F/R):-50~-55/-65~-70
Maximum adjustment range (mm) (F/R):-45~-200/-65~-130
Recommended spring rate (kg/mm) (F/R):18.0/10.0
JAN:827585
Damping force adjustment (F/R):○/○
Number of adjustment steps (F/R):36/36
Overall length adjustment (F/R):○/○
Front camber adjustment: ×
Rear height adjustment: Screw type
Matching grade: F Sport
Note: AVS function will be cut. Matching vehicle is left-hand drive vehicle (GRL10L / USA specification), spring rate selection range F only 14-24K, rear genuine upper mount reused
Remarks
The AVS function is cut off. Matching vehicle is a left-hand drive vehicle (GRL10L/USA model), spring rate selection range F only 14-24K, rear genuine upper mount is reused. CAN ONLY BE SHIPPED WITH UPS OR FEDEX
Notes
Images are for illustration purpose only. Actual product may vary.
