$1,998.00 SGD $2,350.00 SGD
| /
| Brand | TEIN |
| Series Name | MONO RACING COILOVER SUSPENSION KIT |
| Product Number | VSB56-K1NS1 |
| Compatible Car | HONDA CIVIC TYPE R FD2 |
| Product Description | Model year: 2007.03-2010.08 Engine/Drive system: 2000 FF Model: FD2 Grade: TYPE R Springs included: Yes, can be changed EDFC compatible: Yes Damping force adjustment (F/R): Yes/Yes Overall length adjustment (F/R): Yes/Yes Mount (F/R): Yes CAMBER CASTER ADJ/- STD Standard vehicle height compared to factory (F/R): -25/-30 Standard spring rate (N/mm / Kgf/mm) (F/R): 156.9/16.0 / 137.2/14.0 Standard spring free length (mm) / Inner diameter (mm): 130/Φ65 / 142/- |
| Remarks | [Notes] When using the camber adjustment collar in the positive position, if you want to change the direction to the positive direction, use part number SPS12-R16100-25. If you want to adjust the direction to the negative direction, use part number SPS12-R16100-05. When using the camber adjustment collar in the negative position, if you want to change the direction to the positive direction, use part number SPS12-R16100-05. If you want to adjust the direction to the negative direction, use part number SPS12-R16100-25. Two camber adjustment collars are required per vehicle. Camber adjustment collars are available in different offsets and sold separately. Front springs can be selected from 14, 16, and 18K. Rear springs can be selected from 14 and 16K. [Note: Please contact us separately for spring stock.] |
| Notes | Images are for illustration purpose only. Actual product may vary. |
