$1,859.00 SGD $2,186.00 SGD
| /
| Brand | TEIN |
| Series Name | MONO RACING COILOVER SUSPENSION KIT |
| Product Number | VSU86-K1NS2 |
| Compatible Car | SUZUKI SWIFT SPORT ZC32S |
| Product Description | Model year: 2011.12-2016.12 Engine/Drive system: 1600 FF Model: ZC32S Grade: SPORT Springs included: Yes, can be changed EDFC compatible: Yes Damping force adjustment (F/R): Yes/Yes Overall length adjustment (F/R): Yes/Yes Mount (F/R): - STD/- STD Standard vehicle height compared to factory (F/R): -40/-35 Standard spring rate (N/mm / Kgf/mm) (F/R): 117.7/12.0 / 87.8/9.0 Standard spring free length (mm) / Inner diameter (mm): 135/Φ70 / 180/- |
| Remarks | [Notes] When using the camber adjustment collar in the positive position, if you want to change it to the positive direction, use the part number SPS12-R16110-30. If you want to adjust it to the negative direction, use the part number SPS12-R16110-10. When using the camber adjustment collar in the negative position, if you want to change it to the positive direction, use the part number SPS12-R16110-10. If you want to adjust it to the negative direction, use the part number SPS12-R16110-30. Camber adjustment collars are sold separately with different offsets. Four camber adjustment collars are required per vehicle. The camber adjustment range of the accessories is -3.8° to -1.1°. (Varies depending on individual vehicle differences) Front springs can be selected from 10, 12, and 14K. Rear springs can be selected from 9 and 10K. [Note: Please contact us separately for spring stock. ] |
| Notes | Images are for illustration purpose only. Actual product may vary. |
