$1,859.00 SGD $2,186.00 SGD
| /
| Brand | TEIN |
| Series Name | MONO RACING COILOVER SUSPENSION KIT |
| Product Number | VSUB8-K1NS2 |
| Compatible Car | SUZUKI SWIFT SPORT ZC33S |
| Product Description | Model year: 2017.09+ Engine/Drive system: 1400 FF Model: ZC33S Grade: BASE MODEL, SAFETY PACKAGE Springs included: Yes, can be changed EDFC compatible: Yes Damping force adjustment (F/R): Yes/Yes Overall length adjustment (F/R): Yes/Yes Mount (F/R): - STD/- STD Standard vehicle height compared to factory (F/R): -50/-50 Standard spring rate (N/mm / Kgf/mm) (F/R): 98.1/10.0 / 49.0/5.0 Standard spring free length (mm) / Inner diameter (mm): 140/Φ70 / 128/- |
| Remarks | [Notes] FT: Drilling is required in the center of the upper cap. RR: Requires removal of the genuine rear fog lamp. When using the camber adjustment collar in the positive position, if you want to change it to the positive direction, use part number SPS12-R16110-30, and if you want to adjust it to the negative direction, use part number SPS12-R16110-10. When using it in the negative position, if you want to change it to the positive direction, use part number SPS12-R16110-10, and if you want to adjust it to the negative direction, use part number SPS12-R16110-30. Camber adjustment collars are sold separately with different offsets. Four camber adjustment collars are required per vehicle. The camber adjustment range of the accessories is -5.2° to -2.7°. (Varies depending on individual vehicle differences) Front springs can be selected from 8, 10, and 12K. Rear springs can be selected from 5 and 6K. [Note: Please contact us separately for spring stock. ] |
| Notes | Images are for illustration purpose only. Actual product may vary. |
